Product Overview
The N2XFGBY 3×10 mm² 0.6/1kV power cable is a high-performance, multi-core low voltage cable featuring stranded copper conductors and robust mechanical protection. Designed for industrial applications where superior mechanical stress resistance is required, this cable incorporates an XLPE insulation system paired with a heavy-duty flat galvanized steel wire armour. It delivers exceptional electrical efficiency, thermal stability, and long-term reliability for global infrastructure projects.
Key Technical Specifications
- Conductor: Stranded copper conductor
- Insulation: XLPE (Cross-linked Polyethylene)
- Armour: Flat galvanized steel wire armour with a suitable counter helix
- Rated Voltage (Uo/U): 0.6/1 kV
- Cross-Sectional Area: 3 x 10 mm²
- CPR Classification: Eca
| Parameter | Specification |
| Cable Designation | N2XFGBY |
| Conductor Type | Multi-core, Stranded Copper |
| Insulation Material | XLPE |
| Armour Type | Flat Galvanized Steel Wire |
| Rated Voltage | 0.6/1 kV |
| Standard | TS IEC 60502-1 |
Applications & Installation
The N2XFGBY 3×10 mm² cable is engineered for fixed installations in industrial plants, power stations, underground routing, cable ducts, and switching stations. The flat galvanized steel wire armour provides outstanding protection against high tensile loads and mechanical impacts, making it ideal for direct burial and harsh operational environments where external mechanical damage is a risk.
Standards & Compliance
Manufactured in strict accordance with TS IEC 60502-1 standards, this cable meets international benchmarks for safety, material composition, and electrical performance. It carries an Eca CPR classification, ensuring compliance with European Construction Products Regulation requirements for reaction to fire in building installations.
