Product Overview
The 052XZ1-F 5×25 mm² 300/500V cable is an advanced multi-core flexible industrial cable designed for high-integrity electrical installations. Manufactured in compliance with TS 13751 standards, this cable features finely stranded bare copper conductors, premium XLPE insulation, and a halogen-free, low smoke compound outer sheath. It is engineered to deliver reliable power distribution in environments requiring enhanced fire safety, low toxicity emissions, and superior mechanical flexibility.
Key Technical Specifications
This product is built to rigorous technical parameters to ensure dependable performance in demanding electrical networks. Below is a detailed summary of the core specifications for the 052XZ1-F 5×25 mm² cable:
| Cable Designation | 052XZ1-F |
| Cross-Sectional Area | 5×25 mm² |
| Rated Voltage (Uo/U) | 300/500V |
| Conductor Material | Fine stranded multi-core copper |
| Insulation Material | XLPE (Cross-linked Polyethylene) |
| CPR Fire Classification | Cca-s1, d2, a1 |
| Core Characteristics | Halogen-free, flame retardant, low smoke |
| Manufacturing Standard | TS 13751 |
Applications & Installation
With its high degree of flexibility and excellent fire performance properties, the 052XZ1-F 5×25 mm² cable is ideally suited for fixed installations in public buildings, industrial facilities, control panels, and areas with high concentrations of people and sensitive electronic equipment. Its halogen-free and low-smoke emission characteristics (s1, a1) prevent the release of toxic gases and dense smoke during a fire, ensuring clear evacuation routes and protecting vital infrastructure. The flexible fine-stranded copper conductor also facilitates efficient routing in tight spaces and complex cable trays.
Standards & Compliance
Cable Export supplies products that adhere strictly to internationally recognized safety and quality frameworks. The 052XZ1-F cable complies with:
- TS 13751 manufacturing standards
- Construction Products Regulation (CPR) class Cca-s1, d2, a1 for optimal reaction to fire
- Halogen-free and flame-retardant material compliance
